TERAL HORIZONTAL MULTISTAGE PUMP AB 40 x 322 TPC

TERAL HORIZONTAL MULTISTAGE PUMP

MODEL: AB 40 x 322 TPC

MOTOR: 1.10 kW, 1 x 220-240v, 50Hz / 3 x 380-415v , 50Hz

Max Flow: 11 m3/h

Max Pressure: 38m / 3.8 Bar

Pipe connection: 40mm x 32mm (Rp 1½” x Rp 1¼”)

Application

• Household – 7 Bath room
• Liquid Transfer & Circulation
• Pressure Boosting
• Laundry
• Water supply

Pump Specification

• Clean liquid without solid particles
• Liquid temperature range 0⁰C - 90⁰C
• Maximum ambient temperature 50⁰C

Pump Material List

• Pump head – Cast iron
• Intermediate Chamber / impeller / Shaft – SS 304
• Mechanical Seal – Silicon carbide / Carbon
• O-ring – EPDM

Benefit

• Maintains constant water pressure
• Dry running protection
• Quiet operation , Quality assurance , Easy installation
• Space saving
